Shuliy machine nepal egg tray production machine with hot press

  • >=1 Sets
    $3,500.00
Model Number:
SL-4000
Lead Time:
Quantity(Sets) 1 - 2 >2
Est. Time(days) 30 Negotiable
Contact Supplier
Report Suspicious Activity
Overview
Product Hightlights
Product Type Processing Type Power(W)
Egg Tray Machine Pulp Molding Machine 28 kw
Specifications
After-sales Service Provided:
Online support
Warranty:
1 Year
Condition:
New
Place of Origin:
China
Brand Name:
Shuliy
Voltage:
380v
Dimension(L*W*H):
2.3*1.2*1.6m
Weight:
1500KG
Certification:
ISO
Production Capacity:
4000 PCS/H
Name:
Pulp Egg Tray Machine
Raw material:
Waste paper,Newspaper,ect
Finished Products:
Egg tray,Cup holder,Mask,ect
Product name:
Paper Pulper Machine
Application:
Egg Tray Moulding
Production:
Paper Pulp Egg Tray Moulding
Color:
Customized Color
Type:
Recyled
Usage:
Turkey Quail Egg Tray Molding Forming machine
Working speed:
7 times/min
Supply Ability
Supply Ability:
500 Set/Sets per Month
Packaging & Delivery
Packaging Details
1.Outside package:Standard export wooden case
2.Inner package:Stretch film
Port
Qingdao
Lead Time :
Quantity(Sets) 1 - 2 >2
Est. Time(days) 30 To be negotiated

Shuliy machine nepal egg tray production machine with hot press

Product Description



Our egg tray making machine is suitable for variety scale production plant.
It can produce egg cartons, egg box, egg tray, bottle holder, agricultural culture fruit tray, coffee cup tray,ect.The product can be recycled, is a new green packaging, is not only the development of environment-friendly enterprise, also long get rich choice.

Parameter of Egg Tray Machine(4000 pcs/h)

Pulping System

Model:SLPT-4.0

Voltage:380v/50hz

Power:11kw

Volume:5 cbm

Dimension:2200*1800*2200mm

Capacity:500kg/h

Forming System

Model:SLPT-4000

Voltage:220v/380v/50hz

Power:3kw

Capacity:4000pcs/h

Template size:1230*400mm

Operating speed:6 times/min

Size:3200*2200*2500mm

Drying System

Type:Multi-layer dryer

Size:10000*1800*2200mm

Hot Press Shaping System

Model:SL-30

Voltage:AC220V±10%

Power:15kw

Working pressure:30 T

Hot pressing temperature:0-180℃(Adjust)

Dimension:1000*800*2300mm

Capacity:600 pcs/h



About 4000 type Egg Tray Machine,offer detail tested results for your reference:

Workshop:More than 800 square meters,Height more than 4 m .

Production capacity:3000 pcs/hour.(30-eggs tray, ~65g/pc).

Electricity consumption: ~80KW.

Water consumption:~450kgs/hour

Gas natural:40-60m3/h

Raw material: newspaper, carton paper

Raw material consumption: 105-135 kgs/hour

Workers:4~6 person

Paper Pulp Tray Analysis for Reference

(30 pcs paper tray as a reference,Size 300*300*45mm,Weight 65 g/pcs,Capacity 1000 pcs/h)

Our egg tray machines are used in a wide range of applications.Like 4 psc egg tray with lid,30 pcs duck egg tray ,Fruit tray,Wine tray,Cup tray,ect.If you wants to make a special shape of the egg tray, you can send us the design drawings or samples,.Our engineers will design according to the customer's requirements. If you wants to customize the company logo on the egg tray, we can do it too. For more detailed requirements, please contact us.

Because the customer capacity and requirement are different, please let us know your production and demand, we will offer the perfect solution for you.Generally speaking, the complete egg tray machine production line is configured as follows:

1. Put the prepared raw materials, such as waste paper boxes, newspapers, etc., into the hydraulic pulping machine slurry. The pulp fibers are formed under the action of shearing force and friction of the water flow, and the prepared pulp is introduced into the storage tank for use.
2. Introduce the pulp in the slurry tank into the first homogenization tank, while filtering out the impurities in the pulp to adjust the pulp concentration.
3. Introduce the adjusted concentration of pulp into the second homogenization tank for the second agitation treatment. Add the pigment or water repellent and other materials as needed to stir well.
4. The slurry pump draws the adjusted pulp into the molding machine for molding. When the molding die above the slurry tank is completely immersed in the slurry, the slurry is adsorbed and gathered toward the surface of the mold under the vacuum suction on the back of the molding die; because the surface of the molding die is uniquely filtered with a hollow structure, it is gathered. The pulp fibers in the slurry adhere to the surface of the mold, and the water is pumped away to form a wet sputum. The wet sputum adheres to the surface of the mold.
5. When the molding machine is formed, the moisture in the pulp is pumped out through the vacuum pump, and the extracted sewage is discharged into the sewage pool.
6. The sewage in the sewage pool can be recycled, and the sewage is introduced into the hydraulic pulping mechanism slurry or the homogenizing pool to adjust the pulp through the sewage pump.
7. The tray wet tissue layer attached to the surface of the mold is about 2.5 mm thick. It contains about 75% moisture and needs to be sent to the drying line (temperature 120-180 ° C) to remove water.
8. Pack the dried egg tray into the warehouse.

Packaging & Shipping

Any question,please feel free to contact me.

Our Services

We support the technical personnel to help client install and training.

FAQ

Q:How to choose a suitable egg tray making machine and production lines?
A:Just need tell us your requirement.We will make a good production plan according to your requirements.
Q:Do you provide sample service?
A:We can send you paper samples, which is produced by our machine.
You also can send us the paper sample that you want to produce by DHL, etc.We will design according to your paper samples.
Q:What is the raw material of egg tray making machine?
A:Waste paper,Cardboard,Magazine,Newspaper,ect.
Q:Can you offer technician aboard for training workers?
A:Yes, we have team for installation guidance aboard, technicians will be sent for installation guidance and training workers .
Q: What's the guarantee for the egg tray machine and equipment?
A: Usually the forming machine guarantee is one year, and motors guarantee is half of an year.
Q:Where is your company located?
A: it is located in Zhengzhou city, Henan, china.
